d(mm) |
20 |
25 |
32 |
40 |
50 |
63 |
75 |
90 |
110 |
125 |
140 |
160 |
200 |
225 |
250 |
280 |
315 |
355 |
400 |
450 |
500 |
|
Kod |
513000202 |
513000252 |
513000322 |
513000402 |
513000502 |
513000632 |
513000752 |
513000902 |
513001102 |
513001252 |
513001402 |
513001602 |
513002002 |
513002252 |
513002502 |
513002802 |
513003152 |
513003554 |
513004004 |
513004505 |
513005005 |
|
DN(mm) |
15 |
20 |
25 |
32 |
40 |
50 |
65 |
80 |
100 |
125 |
125 |
150 |
200 |
200 |
250 |
250 |
300 |
350 |
400 |
|
|
|
D(mm) |
28 |
34 |
42 |
51 |
62 |
78 |
92 |
111 |
133 |
150 |
167 |
193 |
234 |
257 |
278 |
310 |
348 |
388 |
442 |
|
|
|
D1(mm) |
65 |
75 |
85 |
100 |
110 |
125 |
145 |
160 |
180 |
210 |
210 |
250 |
295 |
295 |
350 |
350 |
400 |
460 |
515 |
|
|
|
D2(mm) |
96 |
105 |
115 |
140 |
150 |
165 |
185 |
200 |
220 |
250 |
250 |
285 |
340 |
340 |
395 |
395 |
445 |
505 |
565 |
|
|
|
n(mm) |
14 |
14 |
14 |
14 |
18 |
18 |
18 |
18 |
18 |
18 |
18 |
18 |
22 |
22 |
22 |
22 |
22 |
22 |
26 |
|
|
|
Z(mm) |
11 |
12 |
14 |
15 |
16 |
18 |
20 |
22 |
24 |
26 |
26 |
28 |
32 |
32 |
36 |
36 |
36 |
38 |
42 |
|
|
|
Kg/Adet |
0,088 |
0,108 |
0,158 |
0,240 |
0,236 |
0,308 |
0,420 |
0,528 |
0,622 |
0,822 |
0,712 |
1,052 |
1,518 |
1,174 |
2,124 |
1,550 |
1,950 |
4,250 |
4,200 |
|
|
|
Kolideki Adet |
150 |
110 |
80 |
50 |
48 |
25 |
40 |
35 |
22 |
18 |
18 |
14 |
8 |
8 |
7 |
7 |
6 |
1 |
1 |
|
|
|
Basınç |
16 |
16 |
16 |
16 |
16 |
16 |
16 |
16 |
16 |
16 |
16 |
16 |
16 |
10 |
10 |
10 |
10 |
10 |
10 |
|
